Kingston 4GB 1333 MHz 240-Pin DDR3 SDRAM Memory Module (KVR13N9S8/4)

sachin emitra
image from amazon.in

DESCRIPTION This document describes ValueRAM's 512M x 64-bit (4GB) DDR3-1333 CL9 SDRAM (Synchronous DRAM), 2Rx8 memory module, supported sixteen 256M x 8-bit DDR3-1333 FBGA components. The SPD is programmed to JEDEC commonplace latency DDR3-1333 temporal arrangement of 9-9-9 at one.5V. This 240-pin DIMM uses gold contact fingers. The electrical and mechanical specifications square measure as follows: FEATURES • JEDEC commonplace one.5V (1.425V ~1.575V) Power-Supply • VDDQ = 1.5V (1.425V ~ 1.575V) • 667MHz fCK for 1333Mb/sec/pin • eight freelance internal bank • Programmable CAS Latency: nine, 8, 7, 6 • Programmable Additive Latency: zero, CL - 2, or CL - one clock • Programmable CAS Write Latency(CWL) = seven (DDR3-1333) • 8-bit pre-fetch • Burst Length: eight (Interleave with none limit, consecutive with starting address “000” only), four with tCCD = four that doesn't allow seamless browse or write [either on the fly victimization A12 or MRS] • Bi-directional Differential information strobe light • Internal(self) standardization: Internal self-calibration through ZQ pin (RZQ: 240 ohm ± 1%) • On Die Termination victimization ODT pin • Average Refresh amount of seven.8us at less than 85°C, 3.9us at 85°C < 95°C • Asynchronous Reset • PCB: Height zero.740” (18.75mm), double-sided part
